| 品牌 | 赢彩数码 |
|---|---|
| 型号 | UV6012 |
1、一机多用，一台机器可以同时装配弱溶剂、纺织、UV等多种墨水进行打印
2、双爱普生喷头，打印效果更精细，效率更高，适合工业化企业
3、双UV（LED）灯交替闪亮，节能环保，也使墨水固化更充分
4、水循环制冷，使UV灯保持恒温，高效工作，延长使用寿命
5、采用雾喷式喷墨方式，避免打印过程中出现横纹，拉丝现象
6、自动搅拌装置，加大墨水自动循环能力，提高白色墨水的流畅性
7、使用直线静音导轨，使机器在打印过程中更加平稳，无噪音，精确度更高
机器参数
型号 | UV0612 | 打印尺寸 | 610mm*1200mm | |
打印头技术 | 低墨可控压电技术 | UV灯类型 | LED | |
颜色模式 | 4色/5色 | 墨盒个数 | 8个 | |
喷头排列 | (180孔*8)*2个喷头 | 最大承重 | 100KG | |
喷头高度 | 0-150mm（可调） | 通讯接口 | USB2.0/IEEE1394 | |
凹凸程度 | 10mm | 电源 | AC100-120V/AC220-240V | |
打印语言 | 英文/中文 | 操作系统 | Window98,NT,2003,XP,Win7 | |
打印方向 | 智能双向打印 | 功率 | 800W | |
打印 速度 | 360*360dpi | 22平方/小时 | 设备重量 | 200KG |
720*720dpi | 15平方/小时 | 设备尺寸 | 200*180*110cm | |
1440*720dpi | 10平方/小时 | 噪音 | 不大于50d8 | |
1440*1440dpi | 8平方/小时 | 使用环境 | 温度：15-30C 温度：20-80（无凝结） | |
应用行业：
1、陶瓷行业：采用数码直喷工艺取代了传统手绘，不仅打印效果精美，也可大批量生
产。瓷砖，瓷板，墙砖，石板装饰墙，马赛克背景墙等广泛应用。
2、家具装修行业：背景墙装饰，工艺玻璃，玻璃装潢、装饰。
3、塑料玩具厂，家电塑料外壳，电子产品塑料外壳、塑料制品厂。
4、金属板材厂，家电金属外壳，铁制品工艺厂，金属包装制品厂。
5、家具厂，家具板材数码彩印，橱柜门，衣柜门，浴室柜等家私厂印刷家具。
6、广告公司个性创意，制作各种商务礼品，工艺美术广告，标牌。
7、服装、纺织、皮革等工厂印刷产品。
8、塑胶、U盘、玩具、电子产品外壳等工厂打印产品
Main features:
1, one machine, a machine can assemble weak solvent at thesame time, textile, UV and other ink for printing
2, double epson nozzle, printing effect is moresophisticated, more efficient and suitable for industrial enterprises
3, double UV (LED) light shine alternately, energyconservation, environmental protection, also make the ink curing more fully
4, water circulation cooling, to keep the UV lamp constanttemperature, efficient work, prolong service life
5, using spray fog and ink, avoid horizontal grain appearedin the process of printing, wiredrawing phenomenon
6, automatic mixing plant, increase the ink automatic cycleability, improve the fluency of white ink
7, use linear mute guide, make the machine more smoothly inthe process of printing, no noise, higher accuracy
The machine parameters
model | UV0612 | The print size | 610mm*1200mm | |
The print head technology | Low ink controlled piezoelectric technology | The UV lamp type | LED | |
Color pattern | 4 color / 5 color | The number of the cartridge | 8 | |
Nozzle arrangement | (180 hole * 8) * 2 nozzle | The largest bearing | 100KG | |
Nozzle height | 0-150 - mm (adjustable) | Communication interface | USB2.0/IEEE1394 | |
Concave and convex degree | 10 mm | The power supply | AC100-120V/AC220-240V | |
Print language | English/Chinese | The operating system | Window98,NT,2003,XP,Win7 | |
The print direction | Intelligent bidirectional printing | power | 800W | |
print | 360*360dpi | 22 square/hours | Equipment weight | 200KG |
720*720dpi | 15 square/hours | The equipment size | 200*180*110cm | |
1440*720dpi | 10 square/hours | The noise | No more than 50 d8 | |
1440*1440dpi | Eight square/hours | Using the environment | Temperature: 15 to 30 c temperature: 20-80 (no condensation) | |
Application industry:
1, the ceramic industry: using digital direct injectiontechnology replaces the traditional hand-painted, print effect not onlyelegant, also for the bulk
Production.Ceramic tile, porcelain plate, wall tile, stonedecorative wall, Mosaic wall and so on are widely used in the background.
2, furniture decoration industry: background walldecoration, craft glass, glass decoration, decoration.
Plastic shell 3, plastic toy factory, home appliance,electronic products, plastic shell, plastic products factory.
metal case 4, sheet metal factory, home appliance, ironproducts processing factory, metal packaging products factory.
5, furniture factory, digital color printing platefurniture, cabinet door, wardrobe doors, bathroom cabinet furniture factory,such as printing and furniture.
6, the individuality creative advertising company, manufactureall kinds of business gifts, arts and crafts advertising, signs.
7, clothing, textile, leather and other printing productsfactory.
8, plastics, U disk, electronic products, toys, such asfactory print products
