| 电压 | 24V |
|---|---|
| 分类 | 步进电机 |
| 工作形式 | 转动 |
| 执行标准 | 国标 |
| 重量 | 3kg |
| 准入认证 | ROHS |
| 产地 | 江苏 |
| 额定电流 | 3A |
| 额定电压 | 24V |
| 额定转矩 | 1NM |
| 额定转速 | 1000 |
| 极数 | 2极 |
| 类型 | 无刷直流电动机 |
| 品牌 | 常州博宏电器有限公司 |
| 型号 | 57HB56F |
| 加工定制 | 是 |
| 质量认证 | CE |
57BYGHB 1.8°两相
| 型号 Series Model | 机身长 Motor Length | 相电压 Rate Voltage | 相电流 Rated Current | 相电阻 Phase Resistance | 相电感 Phase Inductance | 静力矩 Holding Torque | 引线数 Lead Wire | 转动惯量 Rotor Inertia | 重量 Motor Weight |
| (mm) | (V) | (A) | (Ω) | (mH) | (N.M) | (NO.) | (g.cm?) | (Kg) | |
| 57HB41F05B | 41 | 6 | 0.5 | 12 | 20 | 0.4 | 4 | 120 | 0.45 |
| 57HB41F105B | 2.7 | 1.5 | 1.8 | 4 | 0.4 | 4 | |||
| 57HB51F06B | 51 | 7.2 | 0.6 | 12 | 25 | 0.7 | 4 | 275 | 0.65 |
| 57HB51F2B | 2.6 | 2 | 1.3 | 4 | 0.9 | 4 | |||
| 57HB56S06B | 56 | 12 | 0.6 | 20 | 25 | 0.8 | 6 | 300 | 0.7 |
| 57HB56F2B | 3.6 | 2 | 1.8 | 2.5 | 0.9 | 4 | |||
| 57HB64S2B | 64 | 3.4 | 2 | 1.7 | 3 | 1.0 | 6 | 360 | 0.85 |
| 57HB64S3B | 2.4 | 3 | 0.8 | 1 | 0.9 | 4 | |||
| 57HB78S1B | 78 | 8.6 | 1 | 8.6 | 18 | 1.5 | 6 | 480 | 1.1 |
| 57HB78S3PJ | 3.6 | 3 | 1.2 | 2.5 | 1.5 | 6 | |||
| 57HB78F105AB | 6.75 | 1.5 | 4.5 | 15 | 1.8 | 4 | |||
| 57HB78S3B | 3 | 3 | 1 | 1.6 | 1.4 | 6 | |||
| 57HB82E105B | 82 | 7.5 | 1.5 | 5 | 10 | 1.6 | 8 | 530 | 1.2 |
