| 材质 | 金属 |
|---|---|
| 功率 | 0 |
| 规格 | M1.6-M6 |
| 耗气量 | 4.5 |
| 空载转速 | 1900 |
| 类型 | 定扭矩气动起子 |
| 适用范围 | M1.6-M6 |
| 外形尺寸 | 195 |
| 重量 | 0.55 |
| 品牌 | 台湾飞特 |
| 加工定制 | 是 |
| 驱动杆尺寸 | 1/4 |
型号/直柄触压启动SP系列 | 扭矩范围 软连接 | 空转速度 | 重量 | 长度 | 中心边缘距离 | 空转时耗气量 | 软管尺寸 | 进气口螺纹 | |||
Nm | in lb | r/min | kg | lb | mm | mm | l/s | cfm | mm | mm | |
FTL-10SP1 | 0.6-1.6 | 5.3-14.2 | 1900 | 0.55 | 1.2 | 195 | 17 | 4.5 | 10 | 6 | 1/8 |
FTL-10SP2 | 0.4-2.3 | 3.5-20.4 | 1450 | 0.55 | 1.2 | 195 | 17 | 4.5 | 10 | 6 | 1/8 |
FTL-10SP3 | 0.4-3.2 | 3.5-28.3 | 1000 | 0.55 | 1.2 | 195 | 17 | 4.5 | 10 | 6 | 1/8 |
FTL-10SP4 | 0.4-4.2 | 3.5-37.2 | 750 | 0.55 | 1.2 | 195 | 17 | 4.5 | 10 | 6 | 1/8 |
FTL-10SP5 | 0.4-5 | 3.5-44.2 | 450 | 0.55 | 1.2 | 195 | 20 | 4.5 | 10 | 6 | 1/8 |
FTL-20SP1 | 1.1-2.5 | 9.7-22.1 | 3500 | 0.75 | 1.7 | 211 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP2 | 0.6-3.2 | 5.3-28.3 | 2100 | 0.75 | 1.7 | 211 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP3 | 0.5-4.0 | 4.4-35.4 | 1600 | 0.75 | 1.7 | 211 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP4 | 0.7-4.5 | 5.9-38.2 | 2300 | 0.75 | 1.7 | 211 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP5 | 0.4-5.0 | 3.5-44.2 | 260 | 0.75 | 1.7 | 211 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP6 | 1.5-6.0 | 13.3-53.1 | 1000 | 0.75 | 1.7 | 211 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP7 | 1.5-8.0 | 13.3-70.8 | 1100 | 0.9 | 2.0 | 224 | 20 | 7 | 15 | 8 | 1/4 |
FTL-20SP8 | 3.5-10.0 | 31-88.5 | 700 | 0.95 | 2.1 | 232 | 22 | 7 | 15 | 8 | 1/4 |
FTL-20SP9 | 3.5-12.0 | 31-106.2 | 850 | 1 | 2.2 | 246 | 22 | 8.5 | 15 | 8 | 1/4 |
FTL-20SP10 | 3.5-12.5 | 31-110.6 | 450 | 0.9 | 2.0 | 224 | 22 | 7 | 15 | 8 | 1/4 |
FTL-20SP11 | 3.5-12.5 | 31-110.6 | 260 | 0.9 | 2.0 | 224 | 22 | 7 | 15 | 8 | 1/4 |
FTL-20SP12 | 3.5-12.5 | 31-110.6 | 350 | 0.95 | 2.1 | 224 | 22 | 7 | 15 | 8 | 1/4 |
