二、技术数据（Electrical Specifications): | | | | | | | | 电机型号 | 步距角 | 机身长 | 电压 | 电流 | 电阻 | 电 感 | 静力矩 | 引线数 | 转动惯量 | 重量 | | model | step angle | Length | Rated Votage | Rated Current | Phase Resistane | Phase Inductance | Holding Torque | Lead Wire | Rotor Inertia | Motor Weight | | | (°) | L(mm) | (V) | (A) | (Ω) | (mH) | (N.m) | (Num) | (g.cm2) | (kg) | | 86BYGH001 | 1.8 | 66 | 1.89 | 3 | 0.63 | 2.8 | 2.5 | 4 | 0.85 | 1.6 | | 86BYGH101 | 1.8 | 75 | 6 | 3 | 3 | 1 | 3.1 | 4 | 0.85 | 1.9 | | 86BYGH102 | 1.8 | 75 | 2.56 | 3.2 | 0.8 | 7.5 | 3.45 | 4 | 0.85 | 1.9 | | 86BYGH103 | 1.8 | 75 | 1.5 | 5 | 0.3 | 2.5 | 3.45 | 4 | 0.85 | 1.9 | | 86BYGH201 | 1.8 | 80 | 2 | 5 | 0.4 | 3.5 | 3.45 | 4 | 1.6 | 2.1 | | 86BYGH202 | 1.8 | 80 | 3.5 | 4 | 0.86 | 7.34 | 3.5 | 4 | 1.6 | 2.2 | | 86BYGH301 | 1.8 | 98 | 1.6 | 4 | 0.4 | 3.5 | 5.5 | 4 | 1.7 | 3 | | 86BYGH401 | 1.8 | 114 | 6.4 | 2 | 3.2 | 12 | 4 | 8 | 2.7 | 3.6 | | 86BYGH1148 | 1.8 | 114 | 3 | 5 | 0.6 | 6 | 7 | 4 | 3 | 3.6 | | 86BYGH601 | 1.8 | 126 | 5.8 | 4.5 | 1.4 | 10 | 8 | 8 | 4 | 4.3 | | 86BYGH602 | 1.8 | 126 | 3.4 | 5.4 | 0.63 | 5.8 | 7.4 | 4 | 4 | 4.3 | | 86BYGH604 | 1.8 | 126 | 9.72 | 3.6 | 2.7 | 31 | 8.6 | 4 | 4 | 4.3 | | 86BYGH501 | 1.8 | 118 | 2.5 | 5 | 0.51 | 5.8 | 6.5 | 8 | 3.21 | 3.9 | | 86BYGH701 | 1.8 | 150 | 7.8 | 2 | 4 | 20 | 7.6 | 8 | 3.6 | 5 | | 86BYGH603 | 1.8 | 150 | 2.5 | 5 | 0.5 | 5.5 | 10 | 4 | 3.6 | 5 | | 86BYGH801 | 1.8 | 156 | 4.4 | 6 | 0.74 | 9.6 | 12 | 4 | 4.8 | 5.6 |
三、外型图(Mechanical Dimensions) ![]() |
