Electrical Specifications(技术数据):
| 型号SeriesModel | 步距角StepAngle(°) | 机身长MotorLength(mm) | 电流RatedCurrent(A) | 电阻PhaseResistance(Ω) | 电感PhaseInductance(mH) | 静力矩HoldingTorque(N.cm Min) | 定位力矩DetentTorque(N.cm Max) | 转动惯量RotorInertia(g.cm2) | 引线数LeadWire(No.) | 重量MotorWeight(g) |
| 8HY2402 | 1.8 | 28 | 0.2 | 23 | 8.2 | 1.4 | 0.2 | 2.5 | 4 | 50 |
| 8HY2406 | 1.8 | 28 | 0.6 | 3.2 | 0.9 | 1.4 | 0.2 | 2.5 | 4 | 50 |
| 8HY3402 | 1.8 | 34 | 0.2 | 25 | 8.4 | 1.8 | 0.3 | 3.2 | 4 | 70 |
| 8HY3406 | 1.8 | 34 | 0.6 | 4.5 | 1.2 | 1.8 | 0.3 | 3.2 | 4 | 70 |
| 8HY4402 | 1.8 | 40 | 0.2 | 32 | 8.8 | 2.6 | 0.5 | 4.5 | 4 | 82 |
| 8HY4406 | 1.8 | 40 | 0.6 | 5.8 | 1.6 | 2.6 | 0.5 | 4.5 | 4 | 82 |
*We can manufacture products according to customer's requirement. 以上仅为代表性产品，派生产品可根据客户要求制作！
